Code:

SWB-120(v. 2.0)

Name:

Buffer power supply system for PoE switches, 52VDC/2x12Ah/120W

Power supply output 2.3 A / 52 V DC / 120 W
power cable included - JACK 5,5 / 2,1
Battery charging current 0.5A
Battery 2 x 12Ah
Efficiency 87%
Dimensions 300 x 350 x 122 [+/-2 mm]
distance from surface: 14 mm
Mounting plate hinged steel sheet, 250 x 180 [+/-2 mm]
Protections SCP, OLP, OVP, UVP, tamper – opening of enclosure
possibility of mounting tamper switch PKAZ067 detects detachment from the wall
Closing bolted (lock assembly possible)
Installation surface-mounted
Indication LED optical indication
Material steel DC01, 1mm, RAL9003 (white), metallic
Warranty 2 years
Accessories 1 x battery series connection cable
4 screws included
